MCM263T 6 Branch Circuit Power Meter Energy Meter

الوصف

The MCM**3T branch circuit power meter is a high-performance energy measurement device designed for the industrial system or equipment. This multi-circuit energy meter takes measurements from 6xthree-phase circuits or *8xsingle-phase circuits. 5A CT connection is supported by default, and **0mA CT is optional for different current measurement requirements.

With multi-communication interface, various I/O, option, it can realize efficient data transmission and remote monitoring, and meet various network environments. Whether in large industrial facilities or complex power systems, the MCM**3T can provide accurate energy measurement and comprehensive management solutions, making it an ideal choice for industrial branch circuit power monitoring.

Up to 6 or *8 branch circuit metering
There are 6 metering chips inside the MCM**3T branch circuit power meter. One piecies of MCM**3T branch circuit power meter can simultaneously measure up to 6 channel three phase circuits or *8 channel single phase circuits within industrial branch circuit powering monitoring applications such as an electrical panel or switchgear.

Multi-communication Port & Multi-protocal Supported
The MCM**3T multi-circuit submeter is equipped with default RS**5 interface. To adpat any installation, it is optional for Ethernet Port, WIFi Port, Cellular Port(4G Port), Zigbee Port, NB-IOT Port, Bluetooth, etc. With multi-port option, the MCM**3T branch circuit power meter is able to supporting various industrial protocols such as Modbus. Due to multi-communication port and multi-protocal supported, it can connect different industrial systems and integrate data communication flexibly and easily.

Mult-combination of Input/Output
The MCM**3T can configurate the DI(digital ), DO(digital output) and PO(pulse output), according to customer needs. They are configured individualy or comibnationly. For example, you can configure 1 DI, 1 DO, and 1 PO togerther. As for MCM**3T branch circuit metering, you also can configure 3 DO or 6 DI for alarms ouput indivigually. 6 digital s can count pulses from pulse output device. 2 Digital Ouputs can send pulses for an energy management system.
