Small Hot And Cold Oil Press Machine

سعر فوب

أحصل على آخر سعر

2000 ~ 4800 USD / Set

1 Set Minimum Order

بلد:

China

نموذج رقم:

YZYX

سعر فوب:

2000 ~ 4800 USD / Set (قابل للتفاوض) أحصل على آخر سعر

الموقع:

China

سعر الحد الأدنى للطلب:

2000 per Set

الحد الأدني للطلب:

1 Set

تفاصيل التغليف:

wooden case

موعد التسليم:

20 to 30 days

القدرة على التوريد:

100 Set per Month

نوع الدفع:

T/T, L/C, Other

مجموعة المنتج :

Oil Mill Machine

الاتصال الآن

Zhengzhou Sinoder Indutech Machinery

China

عضو مجاني

الشخص الذي يمكن الاتصال به Sinoder

Zhengzhou, Henan

الاتصال الآن

مواصفات المنتج

Function:Press Oil Seeds
Application:Mini Edible Oil Mill Plant
Advantage:Energy Saving Low Residual
Raw material:Soybean,peanut,sunflowerseeds, cottonseeds, etc.
Material:Carbon Steel Stainless Steel
Used for:various dried oil seeds

الوصف

Small Scale Cold Oil Press Machine

Single screw oil press machine is the most popular small oil press machine in todays market, especially for small scale oil production plant. it maximizes the oil yield and requires low investment cost. It is mainly composed of pressing cage and a single screw that is equipped within pressing cage. Screw shaft is the most important part of screw oil press. Its technical data, rotate speed, building materials have a great impact on the pressure of pressing cage and the quality of oil and oil cake

Features:

1.Large Capacity: from 1-20T per day in available.

2.High oil extraction rate -compare with old model, multi stage press,one time finish press, increase the oil extraction rate by 2-3%, increase the capacity 35%-50%.

3.Energy saving-- compare with same capacity products, it can reduce 40% power, each hour can saving 6KW/H.

4.High oil purity- vacuum filtration residue, safeguard oil purity, conform to the standard of health.

5.Cover small area-- only need 10-20 square meter can meet the use.

This screw oil press machine suitable for small scale oil factory and medium factory.

YZYX Oil Press Machine Parameters:

Model	Capacity (t/24hr)	Oil in cake	Power	Rotating Speed (r/min)	Overall dimensions (L×W×H) (Reference)	N. W. (Motor not included) (Reference)
YZYX90	1-3 t/d	6-9 %	5.5 kw	32-42	1200×550×1000 mm	285 kg
YZYX95	3-4 t/d	6-9 %	7.5/11 kw	32-42	1620×580×1200 mm	570 kg
YZYX120	4-5 t/d	6-9 %	11 /15kw	32-42	1860×650×1300 mm	680 kg
YZYX130	6-8 t/d	6-9 %	15 /18.5kw	28-40	1950×750×1500 mm	830 kg
YZYX140	7-10 t/d	6-9 %	18.5/22 kw	28-38	2100×820×1400 mm	1000 kg
YZYX168	10-20 t/d	6-9 %	37/45 kw	32-38	2700×1000×1750 mm	1800 kg

If you want to know more the vegetable oil processing machines and cooking oil refinery plants, pls feel free to contact us and send us the detail requirements.
