SFC Automatic high speed 5ply servo flute laminating machine

الوصف

Automatic high speed 5ply servo flute laminating machine is a new generation of high-speed laminating machine developed by our company. It can laminating three sheets of cardboard at once, and can produce three-layer, four layer, five layer, seven layer, and nine layer boards to increase material strength and thickness. The bottom paper adopts a lead edge feeding structure for stable paper feeding, and the servo tracking and correction principle of the top paper. Can achieve a maximum laminating speed of **0 meters/minute. High speed, efficiency, and precision are your ideal choices.

Performance characteristics

1.This machine can laminatecombination of two corrugated boards and any type oftop sheettogether.It can produce two -layer board (cardboard+ cardboard), 3ply,4ply, 5ply, 7plyand other products.
2. Laminating type: corrugated + corrugated + cardboard, corrugated + corrugated, corrugated + cardboard, cardboard + cardboard, cardboard + gray board + cardboard, etc.
3. Bottom paper feeding structure adopts a lead edge feeding, an extended and widened belt with large suction to ensure stable bottom paper and cardboard feeding without damaging the cardboard.

• The host adopts a large roller (**0mm) design for stable operation and high efficiency. The stainless steel mesh roller of the large roller (**0mm) is evenly coated with glue, saving glue amount, and does not throw glue.
• The surface of the laminating roller and pressing roller is made of special polyethylene material, and the glue automatically falls off and is free from wiping.
• Adopting a dual servotop paper correction structure, thetoppaper andbottompaper (cardboard) are automatically detected and servo corrected, ensuring high precision in tracking and adhering to the front gauge of thetoppaper andbottompaper (cardboard). The front gauge can be adjusted independently according to product needs.
• There are two types of paper feeding structures for thetoppaper lifting platform, pre stacking paper structure and non pre stacking paper lifting platform.
• Thebottompaper pressurization device improves the stability of paper feeding for warped paperboard, and the multifunctional paper tray in thebottompaper stacking section is suitable for warped paperboard.
• The main engine bearings are automatically lubricated at regular intervals, ensuring smooth operation and extending the lifespan of the equipment.
• Adopting a reflux glue system to reduce glue loss and stabilize glue adhesion effect.
• Electrical configuration: International brands such as PLC Siemens,main motor and inverter.
• One -click adjustment of the whole machine (just enter the paper size).
• Video monitoring.
