Manual Operated Stainless Steel Ceramic Lined Knife Gate Valve

Description

FREE-VALVEsmanual operated stainless steel ceramic lined knifegatevalves are known as slurry gate valves. Its have simple structure and can cut off medium which contains solid particles and fibers,suitable for some very hard particles or serious erosive mediums.They are installed to replacegeneral metal seated knife gate valves which will be washed out easily,especially suitable for any power plant located on sea side .
Features:
1) Short length of structure,saving material ,lightweight ,easy to install，small space occupation.
2) Seat is designed with single seat type to prevent sticking and accumulation of ash residue.
3) The sealing surface is made of structure ceramic with abrasion resistance and long service life.
4)Stainless Steel valve body material suitable for any corrosive medium
Technical Specification
1) Size Range: NPS2~NPS*4,DN*0~DN**0
2) Pressure Range: Class **0 /PN6 /PN*0
3) Applicable Temperature.: 0~**0℃
4) Connection Type: Flange , wafer
5) Sealing material: engineering ceramics
6) Body Material:CF8, CF8M, CF3M
7) Pressure test:GB/T****7, API**8
8) Face to Face: GB/T****1,ASME B*6.*0
9) Valve body : GB/T****4,ASME B*6.*4
*0)Operating Mode:Manual
Application
FREE-VALVEsmanual operated stainless steel ceramic lined knifegatevalves are suitable for the conveying system with liquid-solid or gas -solid two-phrase medium , such ascoal -water slurry ,ash, mine residue and coal residue incoal washing plant ,iron& steel plant or ash conveying system of power plant , paper pulp in paper industry, sewage and slurry in decontamination plant ,especially useful for the coal power plant over the sea side .
